Victron 100/20 MPPT solar charge controller

Victron SmartSolar MPPT 100/20 Charger

£75.00

Victron SmartSolar MPPT 100/20 Charger

Victron’s Smart Solar MPPT range of controllers help you maximise the amount of energy obtained from your solar panels.  Under cloudy sky conditions when light intensity is continually changing, these ultra-fast controllers can improve energy harvest by up to 30% compared with controllers using older PWM technology, and by up to 10% compared with slower MPPT models.

All of the Smart Solar models have Bluetooth communication built-in which allows you to interface with the controller via the VictronConnect app on your Apple/Android/Windows device. Through this app, you can configure an extensive range of functions on your controller and monitor its performance in real-time and via historical stats.

The controllers also feature low voltage protection for your battery by disconnecting the load output when the battery reaches a pre-set voltage. This will shut the power off to all circuits connected to the load output and prevents the battery being damaged by over-discharge.





This controller is recommended for a maximum panel power of 290W (12V system) or 580W (24V system)

Features

  • Ultra Fast MPPT (Maximum Power Point Tracking) Technology
  • Bluetooth communication built-in
  • Intelligent battery life management
  • Programmable charge algorithm
  • Low voltage battery protection (when using controller load output)
  • Output short circuit protection
  • Battery reverse polarity protection (external fuse)
  • Over-temperature protection
  • 5-year manufacturer’s warranty



SKU: SCC110030210-1 Categories: , Tag:

Description

Victron SmartSolar MPPT 100/20 Charger
MPPT – Ultra Fast Maximum Power Point Tracking

By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.

Remote Monitoring and Control

Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in Bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet with a GX device, the Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both VictronConnect and VRM are free to use. For remote installations – even when there is no internet connection nearby – you may be able to monitor your MPPT by connecting the GlobalLink 520.

  • System voltage: 12V/24/48V autoselect
  • Max. rated charge current: 20A
  • Max. panel power: 290W (@12V) / 580W (@ 24V) / 1160W (@ 48V)
  • Charge voltage for 12V system: Absorption 14.4V / Float 13.8V (adjustable)
  • Charge algorithm: Multi-stage adaptive
  • Max. panel open circuit voltage: 100V
  • Max. panel short circuit current: 20A (18A @ 48V)
  • Peak efficiency: 98%
  • Max. current through load output: 20A continuous
  • Self power consumption for 12V system: 25mA
  • Max. cable size that fits terminals: 6mm²
  • Operating temp: -30 to +60°C
  • Overall dims: 100 (W) x 113 (H) x 60 (D) mm

SKU: SCC110020160R
Victron SmartSolar MPPT 100/20 Charger



DOWNLOAD DATASHEET HERE

DOWNLOAD USER MANUAL HERE

Additional information

Weight1.52 kg
